Description
Dual Zone Door Frame Metal Detector SF-2 ZONE
SF-DUAL ZONE is industry’s first low cost dual-zone walkthrough metal detector. It has been developed to detect clandestine ferrous and non-ferrous metals on the body of a person when asked to pass through the doorframe. It is also equipped with an intelligent LCD counter to indicate the IN, OUT and algebraic sum of the traffic passing through the door frame.
Bar-graph, indicator lamps, sensitivity and alarm controls are provided in the console at the top of the door frame. Only components of the highest quality and proven reliability are employed in the manufacture of ultrashine to ensure a long, trouble-free life. A mother board system with plug-in cards is employed for minimum downtime and ease of serviceability.
-
Features:
- Microcontroller based design.
- Low cost Dual-zone detector.
- Quick installation no training required.
- Automatic zero adjustment.
- LED based Bar-graph indicator.
- Intelligent people counter for entry, exit and algebraic sum.
- Walk and Stop indicators to regulate traffic.
- Detects all metals, alloys and ferrites.
- SMPS power supply for use with 90V to 270V.
- Built in full-function battery backup for over 12 hours.
- Easy to mount and assemble.
Specifications
| Zone count | 2 zone |
|---|---|
| Detection Zones | Dual Zone |
| Range | 2 m |
| Detect height | 2000 mm |
| Passage width | 800 mm |
| Metal Detector Type | Door Frame Metal Detectors |
| Sensitivity level | Adjustable |
| Power supply | 230 V AC |
| Model Name/Number | SF-2 ZONE |
| Brand | ULTRASHINE |
| Alarm Mode | Sound |
| Usage/Application | Restaurant, Office, Factory, Shopping Mall, Airport, Metro Station, Events & Exhibition |
| Color | Grey |
| Metal Type | Ferrous & Non Ferrous |
| Battery Backup | 12 Hours |
| SMPS Power Supply | 90V to 270V |
| Minimum order quantity | 1 Piece |
