Description
Portable Design Alcohol Tester With Printer TP07
The TP 07 is a new type of Breath Alcohol Tester that features Printer and rapid automatic testing capabilities. Many advanced features.
| The parameter name | Specification |
| Measurement Method | Rapid Assessment |
| Operating Mode | Continuous Data Acquistion |
| Measurement Range | 0mg/100mL~ 400mg/100mL(BAC) |
| Sensitivity | 0.5mg/100mL BAC |
| Measurement Unit | mg/L(BrAC),mg/100mL(BAC)Optional |
| Display | 1.4-inch LCD color display; green color indicates sobriety, accompanied by a voice prompt: “Thank you for your cooperation.” |
| When alcohol is detected, the display turns red, accompanied by a voice alert: “You have been drinking.” | |
| Operation Mode | Menu |
| Measurement Accuracy | When the standard gas concentration is 50mg/100mL BAC: |
| When the blowing distance is less than 5cm: ±5.0mg/100mL | |
| When the blowing distance is between 5~10cm: ±6.0mg/100mL | |
| When the blowing distance is greater than 10cm: ±10.0mg/100mL | |
| Measurement Time | 5 Seconds |
| Operating Environmental Conditions Required | Operating Temperature Range: 0~50°C |
| Environmental Humidity: 20~98% | |
| Storage Temperature: -20~70° | |
| Atmospheric Pressure: 600~1400hPa | |
| Weight | 75 g (including the battery) |
| Battery | 1800mAh, capable of conducting over 1000 consecutive alcohol tests (5V1A charging IC) |
| Power Consumption | During alcohol testing: <50mA |
| Sensor | Semiconductor high-precision intelligent sensor |
| Size | Length * Diameter: 120mm * 50mm |
| Power Saving Mode | The device automatically shuts down after 5 minutes in alcohol testing mode. |
| Data | Measurement records are saved locally and can be exported to a computer via USB. |
| Printer | The device activates Bluetooth to connect to the printer for printing. |
Specifications
| Application Type | Law Enforcement |
|---|---|
| Type | Handheld |
| Sensor Type | Fuel Cell |
| Grade | Automatic |
| Model Name | TP-07 |
| Mouthpiece Type | Replaceable |
| Measurement Mode | Active Sampling |
| Portability | Portable |
| Accuracy | ± 5 % |
| Display Type | Digital |
| Packaging Type | Box |
| Usage/Application | Industrial |
| Country of Origin | Made in India |
| Brand | ULTRASHINE |
| Display mode: | 1.4-inch LCD color display |
| Model | TP07 |
| Measurement time | 5 seconds |
| Measuring range | 0mg/100mL~ 400mg/100mL(BAC) |
| Working method: | continuous sampling |
| Using battery | 1800mAh, it can continuously test wine more than 1000 times (5V1A charging IC) |
| The parameter name | Specification |
| Measurement Method | Rapid Assessment |
| Operating Mode | Continuous Data Acquistion |
| Measurement Range | 0mg/100mL~ 400mg/100mL(BAC) |
| Sensitivity | 0.5mg/100mL BAC |
| Measurement Unit | mg/L(BrAC),mg/100mL(BAC)Optional |
| Display | 1.4-inch LCD color display; green color indicates sobriety, accompanied by a voice prompt: “Thank you for your cooperation.” |
| Operation Mode | Menu |
| Measurement Accuracy | When the standard gas concentration is 50mg/100mL BAC: |
| Measurement Time | 5 Seconds |
| Operating Environmental Conditions Required | Operating Temperature Range: 0~50°C |
| Weight | 75 g (including the battery) |
| Battery | 1800mAh, capable of conducting over 1000 consecutive alcohol tests (5V1A charging IC) |
| Power Consumption | During alcohol testing: <50mA |
| Sensor | Semiconductor high-precision intelligent sensor |
| Size | Length * Diameter: 120mm * 50mm |
| Power Saving Mode | The device automatically shuts down after 5 minutes in alcohol testing mode. |
| Data | Measurement records are saved locally and can be exported to a computer via USB. |
| Printer | The device activates Bluetooth to connect to the printer for printing. |
| Minimum order quantity | 1 Piece |
